模塊式精鏜刀

模塊式精鏜刀	Modular Fine Boring Tool

Type																	Dcmm									Lcmm					X1mm				X2mm					Fine Boring Unit														kg						Insert Type
N2-FBA020.WB06																	020-025									25					80				65					FBA020.WB06														0.20						WBGT0601
N2-FBA025.WB06																	025-032									25					80				80					FBA025.WB06														0.30
N3-FBA032.WB08																	032-042									32					80				80					FBA032.WB08														0.50						WBGT0802
N4-FBA042.TC11																	042-055									40					80				80					FBA042.TC11														0.80						TPGT1103
N5-FBA055.TC11																	055-070									50					100				100					FBA055.TC11														1.60
N6-FBA070.TC11																	070-085									63					100				100					FBA070.TC11														2.50
N8-FBA085.TC11																	085-100									80					100				100					FBA085.TC11														4.00
N8-FBA100.TC11																	100-140									80					100				100					FBA100.TC11														5.00

	Insert Type	Dmm	a°	Smm
	WBGT0601	3.969	5	1.59
	WBGT0802	4.762	5	2.38
	TPGT1103	6.35	11	3.18

Material Type

P

M

K

N

Applicable Insert Type

Alloy steel

Stainless steel

Cast iron

Non-ferrous metals

WBGT030102L-M08

FCP20

FCM20

FCK20

FCN20

WBGT060102L-M08

FCP20

FCM20

FCK20

FCN20

WBGT060104L-M08

FCP20

FCM20

FCK20

FCN20

TCGT110202-M08

FCP20

FCM20

FCK20

FCN20

TCGT110204-M08

FCP20

FCM20

FCK20

FCN20
